Large periapical lesion management: Decompression combined with root-canal treatment

Periapical lesions often develop slowly and do not become very large. Patients do not experience pain unless there is acute inflammatory exacerbation. These lesions are often diagnosed during routine radiographic exams. Some periapical lesions become large and, in cases of large radiolucencies, they may be diagnosed in the absence of any patient complaint. Sometimes, symptoms such as mild sensitivity, swelling, tooth mobility and displacement may be observed in these cases.

Large periapical lesions are often associated with anterior maxillary teeth, probably due to traumatic injuries. These lesions could be classified as granulomas, pocket cysts (also called bay cysts) and true cysts. Granulomas are usually composed of solid soft tissue, while cysts have a semi-solid or liquefied central area usually surrounded by epithelium.[1] Pocket cysts have an epithelial lining that is connected with the root canal, and true cysts are completely lined with epithelium and not connected with the root canal.[2]

According to Nair,[3] research based on serial sectioning and strict histopathological criteria demonstrated the prevalence of pocket cysts to be 6 %, whereas that of true cysts is 9 %. Previous studies without serial sectioning that reported ranges from 6 to 55 % are proven to contain a great margin of error.





The differential diagnosis of large periapical lesions is still a controversial topic. Periapical radiographs, contrast media, Papanicolaou smears and albumin tests have proven to be inaccurate in establishing a preoperative diagnosis. Only once the post-operative biopsy has been taken, can a diagnosis be established. There is evidence[1] that CBCT scans may provide a more accurate diagnosis than biopsy.

To obtain an accurate reading, the entire lucency must be scanned for the most lucent or least dense areas. If the least dense area of the CBCT scan shows positive grey-scale values identified as solid tissues, diagnosis will be consistent with granuloma. If it shows negative grey-scale values identifying a semi-solid or fluid-filled central area, diagnosis will be consistent with a pocket or a true cyst. Real-time ultrasound imaging and ultrasound recently demonstrated that they are capable of establishing differential diagnosis as well.[4]

There is widespread agreement that most granulomas heal after non-surgical root-canal treatment (RCT), but there is no consent regarding this in the case of periapical cysts. In Nair’s opinion, based on indirect clinical evidence, it appears that pocket cysts may heal after non-surgical endodontics. He asserts that a pocket cyst is sustained by the microbes within the canal system, but that a true cyst is self-sustaining and will remain after the micro-organisms have been removed from the root-canal system. The new preoperative diagnostic techniques will be helpful in the treatment decision process.

The following case report describes the management of a particularly large maxillary periapical lesion (involving four anterior teeth) by decompression with tubing, followed by non-surgical endodontic treatment using interim long-term calcium hydroxide (Ca(OH)2).

Case report

A healthy 39-year-old male patient with recurrent palatal swelling and buccal abscesses was referred to our practice (Fig. 1). He had had these symptoms for the last two to three years owing to trauma sustained while working with machinery. An RCT on tooth #9 had been performed following the incident. One year later, the tooth presented with apparent brown discolouration according to the patient.

At the initial examination, tooth #9 was found to be non-vital (non-responsive to cold or electrical stimuli), and teeth #7, 8, 10 and 11 had a cold pulpal response within normal limits. Radiographs revealed a large cyst-like periapical lesion that appeared to be centred above the left upper central incisor (Figs. 2 & 3). A panoramic radiograph (Fig. 4) confirmed the full extent of the lesion, which appeared to involve the floor of the nasal sinus. The history of repeated palatal and buccal abscesses suggested a through-and-through osseous defect. The diagnosis was apical periodontitis in tooth #9.

The following treatment options were considered:

_decompression combined with RCT; and
_surgical removal of the lesion with RCT on tooth #9 and possibly teeth #8, 10 and even 7 and 11 owing to the great risk of damaging nervous and vascular supply during surgery.

The patient preferred the most conservative approach and treatment was performed in four appointments over five months.

Management sequence

1. During the first visit, the previous root-canal filling (gutta-percha with a plastic carrier) was removed (Fig. 5). There was a lot of gutta-percha in the pulpal camera. This and remains of necrotic pulpal tissue could have been the cause of the brown staining of the tooth. Once the buccal encapsulated tissue had been removed (Fig. 6), both the tooth and buccal abscess were drained of copious exudate. A Ca(OH)2 paste (UltraCal XS, Ultradent) was placed in the root canal as interim medication (Fig. 7).

2. After one month, Ca(OH)2 was replaced because the canal could not be dried even after shaping and cleaning with copious amounts of 5.25 % sodium hypochlorite. A vestibular incision was made and a plastic cannula was inserted into the lesion, obtaining purulent drainage. Thereafter, the cannula was prepared and sutured to the mucosa (Figs. 8 & 9), and the patient was instructed to irrigate through the lumen of the cannula with 3 ml of 0.12 % chlorhexidine on a daily basis for four weeks (Fig. 10), consistent with the protocol described by Brøndum and Jensen.[5]

3. Two months after the last visit, complete drying of the canal space was achieved but, owing to the extent of the lesion, it was decided to replace and maintain the Ca(OH)2 for two months in order to determine whether this would effect healing as evidenced in the pattern of the lesion.

4. Two months later, healing appeared to be underway (Fig. 11a) and the canal was dry. The root-canal filling was performed with gutta-percha and AH Plus (DENTSPLY DeTrey) and composite were placed to seal the access (Fig. 11b).

The patient was recalled at eight months and was asymptomatic and there was no swelling or abscess at either the palatal or buccal surfaces. Normal pulpal responses have been maintained in teeth #7 to 11 since.

Healing of the lesion still appeared to be in progress. Owing to the reduction in the size of the lesion, the trabecular pattern at the borders of the lesion had been restored (Fig. 11c) and the periodontal ligament around tooth #9 was almost fully recovered (Fig. 12). We plan to recall this patient on a yearly basis until the lesion is fully healed.

Discussion

The management of large periapical lesions is the subject of prolonged debate. The treatment options range from conventional non-surgical RCT with long-term Ca(OH)2 therapy to various surgical interventions, including marsupialisation, decompression with a tube and surgical removal of the lesion. These treatment options can also be combined.

Long-term drainage is important in the conservative management of these large lesions. One method is to drain through the canal on a daily basis until the canal becomes dry. This could last for between 15 days and one month. At each visit, debridement, drying and closing of the access cavity are mandatory. Another method of drainage is decompression with a tube from the apical focus. There is no standard protocol for the length of time for which the tube should be left in. Some clinical cases, however, have reported five-week to 14-month-periods, with periodical reshaping if necessary.

The literature offers evidence that the majority of these cyst-like lesions heal after conventional RCT over multiple appointments. Çaliskan [6] reported 74 % complete healing and 9.5 % incomplete healing in an in vivo study of anterior teeth with large periapical lesions ranging from 7 to 18 mm. The treatment combined long-term canal drainage with Ca(OH)2 dressing and non-surgical RCT. Several case reports [7–9] have demonstrated that long-term decompression involving a tube combined with interim Ca(OH)2 dressing and RCT is also successful.

Decompression is favoured because fewer visits are necessary compared with root-canal drainage. Furthermore, it is much more conservative, especially in comparison with surgical removal of the lesion with the risk of damaging the nervous and vascular supply of adjacent teeth and other anatomical structures, such as the nose and maxillary sinus floor. Even if surgical removal is still necessary later, the lesion will inevitably have shrunk in size by such time and present less difficulty and less risk of damage to other teeth or vital structures.

With complete informed consent, the patient may prefer more immediate therapy and select surgical enucleation without delay in conjunction with the conventional endodontic therapy of the responsible tooth and usually the adjacent ones involved in the lesion. It is important to remember that microbes initially caused the lesion and continue to maintain the immune response and thus the apical periodontitis. The length of time required for healing in these cases ranges from eight to 14 months.[6] Follow-up on the process of healing should be done every six months for four years.

There are also large periapical lesions of non-dental origin, such as non-dental cysts (e.g. nasopalatal cyst) and neoplastic entities. If there are doubts regarding the dental origin of the periapical lesion, the first choice of treatment is the surgical approach.

This case has illustrated the healing of a large periapical lesion with a minimally invasive approach. However, every case requires an individual approach depending on the patient’s cooperation, preferences, availability and proximity to the surgery, as well as the dentist’s professional training and technical skills.

Editorial note: A complete list of references is available from the publisher.
